SC-442-Y-C Half Height Turnstile

SC-442-Y-C Half Height Turnstile

SC-432-Y-C half height turnstiles are generally designed to be used in situations where the passage of crowded groups of people needs to be controlled, such as factories. Two ACS-551 and ACS-451 card readers can be integrated onto the SC-432-Y-C half height turnstile. The SC-432-Y-C half height turnstile can be used as single or double-sided. Direction selection can be easily made by users. It can give an audible warning when desired. Memory feature can be used for multiple passages. Remote passage permission can be given or removed independently of the person passing. Thanks to its optical sensors, information can be obtained about the position, movement and direction of the SC-432-Y-C half height turnstile arms. There is a data output for the counter or other control systems when passage is made. All mechanical parts and electromechanical control systems are manufactured in our facilities. The SC-432-Y-C half height turnstile series, which can be used in indoor and outdoor areas, can be manufactured in electrostatic powder paint or stainless steel.


Body 40x40 mm profile frame, 1.5 mm sheet steel. (Electrostatic powder coated or 304 stainless steel)
Coupling Aluminum casting, precision CNC machining.
Mechanism 6 mm laser cut steel sheet, precision CNC machining, stainless steel impeller. 4 lever mechanism.
Arms 10 mm laser cut plexiglass, 3 rows of arms screwed to the middle rotor.
Dimensions 1380x1250x1300 mm, Arm 550 mm, Transition range 480mm ~175 kg
Indicators Both directions on top panel.
Energy and Power 176-264 V AC 50-60 Hz / 24V DC Max: 25W
Temperature -20 / +60 °C
Working Mode Two-way locked, one-way locked, one-way free, both directions free, adjustable trigger time.
Features Single contact, two-way switching, memory mode, service port, internal operation and transition counters.
Outputs Dry contact pass information separately for both directions, PC control port.
Emergency Free mode with emergency input, free mode when there is no power.
Safety Status With the safety status input, the turnstile goes into locked mode and never opens.
Capacity 20 people / minute
Option RF control card, counter, button, coin unit, reader unit, heater.
